Generac Mobile Diesel Generator TECHNICAL DATA :



Model	AP16000S(-3)
Frequency [Hz]	50 60
Voltage [V]	220,230,240,110/220,115/230,120/240,220/380,230/400,240/415
Rated Power [Kva]	11.0(13.75) 12.0(15.0)
Max. Power [Kva]	12.0(15.0) 13.0(16.0)
Phase Number	Single/Three
Excitation Transistorized	Self-excitation , brush
Power Factor Cos Φ	1.0(0.8)
Insulation Grade	F
Fuel Capacity [L]	26
Noise Level [Db](@ 7m)	75
Engine Model	AP292F
Engine Type	2-cylinder ,4-Stroke, Air-cooled
Starting System	Electric Starting
Broke * Stroke [mm]	2-92 * 75
Displacement [L]	0.997
Compression Ratio	19
Rated Rotation Speed [rpm]	3000 3600
Rated Power [Kw]	14.0 15.0
Lube [L]	2.75

silent type with canopy, 30L fuel tank, AVR type alternator, digital panel, electric start with 36ah battery

Generac Mobile Diesel Generator

Control , monitor and protect the Generator Set including :

High water temperature

Low oil pressure

Over and under speed

Over current

Under / Over generator voltage

Start and stop failure

Low and high battery voltage

Charge fail



Generac Mobile Diesel Generator

The AP1600-3S Mobile Diesel Generator is a superior piece of equipment that is designed to provide reliable and efficient power wherever and whenever it is needed. It is a powerful 4-stroke, 12 kW single-cylinder diesel engine generator that can produce enough electricity to power a variety of residential or commercial appliances.



One of the key features of the AP1600-3S is its portability and mobility. Its compact and lightweight design makes it easy to transport and move around your site, making it perfect for use in construction sites, outdoor events, and emergency power situations.

In addition to its portability, the AP1600-3S also boasts a variety of safety features that ensure that it operates reliably and safely. It has a low oil pressure shutdown feature that automatically switches off the generator in case of low oil pressure.



Another important feature of the AP1600-3S is its fuel efficiency. It features a large fuel tank that is designed to provide long run times, reducing the need for refueling. This generator is also equipped with an automatic voltage regulator that helps to ensure that the power produced is of high quality and stable.



Operators will also appreciate the ease of use of the AP1600-3S. It features an intuitive control panel that allows for easy monitoring of the engine's performance and output. The generator is also equipped with a maintenance-free battery and a self-cleaning air filter that helps to keep the engine running smoothly.



The AP1600-3S Mobile Diesel Generator is a dependable and efficient power source that can be used for a wide range of applications. Whether you need backup power for your home, power for a remote job site, or an emergency power supply during a power outage, this generator is up to the task.



In conclusion, the AP1600-3S Mobile Diesel Generator is a top-performing and reliable piece of equipment that delivers dependable power when you need it most. Its portability, safety features, fuel efficiency, and ease-of-use make it a valuable asset for any project or situation. Choose the AP1600-3S for continuous and stable electricity supply now!
